Heavy Duty Screw Conveyor

Heavy Duty
Large output
Quick-detachable
Vertical Design

BASIC INFO

Screw conveyors,also known as auger conveyor, are made for simple conveying duties applications.The real strength of our company,however,is our ability to produce individually designed units that include features to overcome awkward installations,materials that are difficult to handle,or include performance or process functions beyond simple conveying.Some requirements may be concerned with aspects of hygiene,others with bulk solids that have poor or delicate conveying properties.

Spiral screw conveyor is divided in two types rigid screw conveyor and shaftless screw conveyor.

Spiral screw conveyor is suitable for non-sticky powder and small particle material such as cement,fly ash,lime,flour,starch,food additive etc.

Technical data

Model	Spiral Diameter (mm)	Output (M3/h)	Speed ratio ( m/min)	Power ( Kw)
PL-LS100	100	3	140	1.1
PL-LS160	160	7	112	1.1
PL-LS200	200	12	100	1.5
PL-LS250	250	20	90	2.2
PL-LS315	315	30	80	3
PL-LS500	500	90	63	7.5
PL-LS630	630	120	50	11
PL-LS800	800	250	40	18.5
PL-LS1000	1000	320	32	55
PL-LS1250	1250	400	25	75
